Type
Desmosedici Stradale 90° V4, counter-rotating crankshaft, Desmodromic timing, 4 valves per cylinder, liquid-cooled
Displacement
998 cc (60.9 cu in)
Bore and stroke
81 mm x 48.4 mm (3.2 in x 1.9 in)
Compression Ratio
14.0:1
Power
218 hp (160.3 kW) @ 15,750 rpm
Torque
114.5 Nm (11.7 kgm, 84 lb ft) @ 12,000 rpm
Fuel injection
Electronic fuel injection system. Twin injectors per cylinder. Full ride-by-wire elliptical throttle bodies. Variable length intake system
Exhaust system
4-2-1-2 system, with 2 catalytic converters and 6 lambda probes.
Gearbox
6 speed
Primary drive
Straight cut gears; Ratio 1.80:1
Ratios
1=36/15 2=34/17 3=33/19 4=32/21 5=30/22 6=27/22
Final drive
Chain 520; Front sprocket 16; Rear sprocket 43
Clutch
Hydraulically controlled slipper dry clutch. Self bleeding master cylinder.
Frame
Aluminium alloy "Front Frame" with optimised stiffnesses
Front suspension
Fully adjustable 43 mm Öhlins NPX pressurized fork with TiN treatment.
Front wheel
5-spokes forged aluminium alloy 3.50" x 17"
Front tyre
Pirelli Diablo Supercorsa SP-V4 120/70 ZR17
Real suspension
Fully adjustable Ohlins TTX36 unit with adjustable rebound, compression and hydraulic spring preload. Aluminium Hollow Symmetrical Swingarm. Adjustable pivot position +/- 3 mm. Adjustable rear suspension tie-rod length +/- 5mm
Rear wheel
5-spokes forged aluminium alloy 6.00" x 17"
Rear tyre
Pirelli Diablo Supercorsa SP-V4 200/60 ZR17
Wheel travel
125 mm / 130 mm (4.9 in / 5.1 in)
Front brake
2 x Æ 330 mm semi-floating discs, radially mounted Brembo Monobloc Hypure® 4-piston calipers. Self bleeding master cylinder. ABS cornering with eCBS.
Rear brake
Æ 245 mm disc, 2-piston caliper. ABS cornering with eCBS.
Instrumentation
Digital unit with 6,9" TFT display and Optical Bonding - 480x1280 resolution
Wet weight
186.5 kg (411 lb)
Seat height
855 mm (33.7 in)
Wheelbase
1,477 mm (58.1 in)
Rake
24°
Trail
98 mm (3.9 in)
Fuel tank capacity
17 l (4.5 US gal)
Number seats
1
Safety equipment
Riding Modes, Power Modes, Ducati Slide Control (DSC), Bosch Cornering ABS, Ducati Brake Light (DBL), Ducati Vehicle Observer (DVO), Ducati Traction Control (DTC) DVO, Ducati Wheelie Control (DWC) DVO, Auto tyre calibration, Engine Brake Control (EBC) DVO, Race Brake Control, Road eCBS
Standard equipment
Öhlins suspension, Lithium-ion battery, Quick adjustment buttons, Forged aluminium wheels, Coming Home, Single seat configuration, Ducati Power Launch (DPL) DVO, TFT colour display, Full LED lighting system, Full LED headlight, Daytime Running Light (DRL), Self cancelling turn indicators, Lap Timer, Pit Limiter, Rear susopension rod with adjustable length, Ducati Racing Gearbox (DRG) with Ducati Neutral Lock (DNL), Ducati Quick Shift (DQS) up/down 2.0, Billet aluminium steering stem with bike number, Öhlins SD20 steering damper
Provided equipment
Machined mirror block-off plates*, Open clutch cover in carbon fibre*, License plate mount removal plug*
Ready for
Anti-Theft, Tyre Pressure Monitoring System (TPMS), Cruise control, Ducati Data Logger (DDL), Ducati Multimedia System (DMS), Lap Timer Pro, Heated grips, Turn-by-Turn navigation system, USB port, Passenger seat and footpegs, Linear shock travel sensor
Warranty
24 months, unlimited mileage
Valve clearance check
24,000 km (15,000 mi)
Standard
Euro 5+
Co emissions
167 g/km
Consumption
7.2 l/100 km
Notes
* Equipment not for road use
