Type
Superquadro Mono, single-cylinder, 4 valves per cylinder, Desmodromic timing, 2-balance countershafts, liquid cooled
Displacement
659 cc
Bore and stroke
116 x 62.4 mm
Compression Ratio
13.1:1
Power
57 kW (77.5 hp) @ 9,750 rpm
Torque
63 Nm (46.5 lb-ft) @ 8,000 rpm
Fuel injection
Electronic fuel injection system, Øe 62 mm throttle body with full Ride by Wire system
Exhaust system
1-2 exhaust system, double aluminium mufflers, catalytic converter and lambda probe
Gearbox
6 speed
Primary drive
Straight cut gears; Ratio 1.968:1
Ratios
1=36/13 2=35/17 3=32/20 4=29/22 5=24/21 6=26/25
Final drive
Chain 520; Front sprocket 15; Rear sprocket 42
Clutch
Slipper and self-servo wet multiplate clutch, hydraulic control
Frame
Tubular steel Trellis frame
Front suspension
Ø 45 mm Marzocchi fully adjustable aluminium fork
Front wheel
Y shaped 5-spoke light alloy 3.5" x 17"
Front tyre
Pirelli Diablo Rosso IV, 120/70 ZR17
Real suspension
Progressive linkage with Sachs fully adjustable monoshock. Aluminium double-sided swingarm
Rear wheel
Y shaped 5-spoke light alloy 5.0" x 17"
Rear tyre
Pirelli Diablo Rosso IV, 160/60 ZR17
Wheel travel
215 mm (8.5 in) - 240 mm (9.4 in)
Front brake
Ø 330 mm aluminium flange disc, Brembo M4.32 caliper, radial pump with adjustable lever, with Bosch Cornering ABS
Rear brake
Ø 245 mm disc, single piston floating caliper, with Bosch Cornering ABS
Instrumentation
3.8" LCD display with Improved Black Nematic (IBN) technology
Wet weight
151 kg (333 lb)
Seat height
904 mm (35.6 in) 889 mm (35.0 in) with low seat accessory 849 mm (33.4 in) with low seat + low suspension kit accessory
Wheelbase
1,443 mm (56.8 in)
Rake
26.1°
Trail
108 mm (4.2 in)
Fuel tank capacity
12 l (3 US gallons)
Number seats
2
Safety equipment
Riding Modes, Bosch Cornering ABS, Ducati Traction Control (DTC), Ducati Wheelie Control (DWC), Engine Brake Control (EBC), Ducati Brake Light (DBL)
Standard equipment
Ducati Quick Shift (DQS) up/down, Power Modes, Ducati Power Launch (DPL), Full LED lighting system, Daytime Running Lights (DRL), Tapered aluminium handlebars, Lithium-ion battery, Termignoni type approved silencers, Nera livery
Provided equipment
Passenger footpegs
Ready for
Anti-theft system, Heated grips, Ducati Multimedia System (DMS).
Warranty
24 months unlimited mileage
Valve clearance check
30,000 km (18,000 miles)
Standard
Euro 5+
Co emissions
112 g/km
Consumption
4.8 l/100 km
