Type
Ducati V2 engine: 90° V2, 4 valves per cylinder, intake variable valves timing system, liquid cooled
Displacement
890 cc (54.3 cu in)
Bore and stroke
96 mm x 61.5 mm (3.8 in x 2.4 in)
Compression Ratio
13.1:1
Power
120.4 hp (88.5 kW) @ 10,750 rpm
Torque
94 Nm (9.6 kgm, 69 lb ft) @ 8,250 rpm
Fuel injection
Electronic fuel injection system. One injector per cylinder. Full ride-by-wire.
Exhaust system
2-1-2 system
Gearbox
6 speed with Ducati Quick Shift up/down 2.0
Primary drive
Straight cut gears; Ratio 1.84:1
Ratios
1=38/14 2=34/17 3=32/20 4=29/22 5=24/21 6=26/25
Final drive
Chain 520; front sprocket 15; rear sprocket 42
Clutch
Hydraulically controlled slipper and self-servo wet multiplate clutch. Self bleeding master cylinder
Frame
Monocoque Aluminium
Front suspension
Fully adjustable Ø 46 mm Kayaba front fork
Front wheel
Casted light alloy, 3,50" x 17"
Front tyre
Pirelli Diablo Rosso IV, 120/70 ZR17
Real suspension
Adjustable Kayaba rear shock (pre-load and rebound). Aluminium double-sided swingarm
Rear wheel
Casted light alloy, 5,50” x 17”
Rear tyre
Pirelli Diablo Rosso IV, 190/55 ZR17
Wheel travel
170 mm / 160 mm (6.7 in / 6.3 in)
Front brake
2 x Ø 320 mm semi-floating discs, radially mounted Brembo Monobloc M4.32 4-piston calipers, radial master cylinder. Cornering ABS.
Rear brake
Ø245 mm disc, 2-piston caliper. Cornering ABS
Instrumentation
Digital dashboard with 5'' full-colour TFT display, 800 x 480 px resolution; 16:9 ratio
Wet weight
180 kg (397 lb)
Seat height
880 mm (34,6 in) 865 mm (34,1 in) with low seat accessory 850 mm (33,5 in) with low seat accessory + low suspension kit
Wheelbase
1,514 mm (59.6 in)
Rake
26°
Trail
110 mm (4.3 in)
Fuel tank capacity
12.5 l (3.3 US gal)
Number seats
2
Safety equipment
Riding Modes, Power Modes, Ducati Traction Control (DTC), Ducati Wheelie Control (DWC), Engine Brake Control (EBC), Bosch Cornering ABS, Ducati Brake Light (DBL)
Standard equipment
Ducati Quick Shift (DQS) up/down 2.0, Quick adjustment buttons, Coming Home, TFT colour display, Full LED lighting system, Daytime Running Light (DRL), Sachs steering damper, Dynamic turn indicators, Self cancelling turn indicators, Lap Timer
Provided equipment
Passenger footpegs
Ready for
Anti-Theft, Cruise control, Ducati Multimedia System (DMS), Lap Timer Pro, Heated grips, Turn-by-Turn navigation system, USB port, Ducati Power Launch (DPL), Pit Limiter
Warranty
24 months, unlimited mileage
Valve clearance check
45,000 km (28,000 mi)
Standard
Euro 5+
Co emissions
125 g/km
Consumption
5.4 l/100 km
