Type
Ducati Desmosedici stradale, V4 - 90°, 4 valves per cylinder, counter-rotating crankshaft, twin pulse firing order, semi dry sump, liquid cooled
Displacement
1,103 cc (67.3 cu in)
Bore and stroke
81 mm / 53.5 mm (3.2 in / 2.1 in)
Compression Ratio
14.0:1
Power
180 hp (132.4 kW) @ 12,250 rpm
Torque
118 Nm (12 kgm, 87 lb ft) @ 9,500 rpm
Fuel injection
Electronic fuel injection system, Øeq 50mm equivalent elliptical throttle bodies with Ride-by-Wire system
Exhaust system
Stainless steel pre-silencer, Akrapovič titanium muffler
Gearbox
6 speed with Ducati Quick Shift up/down 2.0
Primary drive
Straight cut gears; Ratio 1.8:1
Ratios
1=40/13, 2=36/16, 3=34/19, 4=31/21, 5=29/23, 6=27/25
Final drive
Chain, Front sprocket Z15; Rear sprocket Z43
Clutch
Multiplate dry clutch with slipper action on over-run
Frame
Aluminium monocoque frame
Front suspension
Öhlins Ø 48 mm fully adjustable usd fork with TiN treatment, electronic compression and rebound damping adjustment with Öhlins Smart EC 2.0 event-based mode
Front wheel
Marchesini light alloy forged, 3.5" x 17"
Front tyre
Pirelli Diablo Rosso IV Corsa 120/70 ZR17
Real suspension
Öhlins TTX36 fully adjustable shock absorber, electronic compression and rebound damping adjustment with Öhlins Smart EC 2.0 event-based mode, electronic preload adjustment, aluminium single-sided swingarm
Rear wheel
Marchesini light alloy forged, 6" x 17"
Rear tyre
Pirelli Diablo Rosso IV Corsa 190/55 ZR17
Wheel travel
170 mm / 170 mm (6.7 in / 6.7 in)
Front brake
2 x Ø 330 mm semi-floating discs, radially mounted Brembo Stylema monobloc 4-piston 2-pad calipers, radial master cylinder, Cornering ABS
Rear brake
Ø 280 mm disc, Brembo 2-piston floating caliper, Cornering ABS
Instrumentation
6.5" TFT colour display with Ducati Connect and full-map navigation system
Wet weight
225 kg (no fuel)
Seat height
Adjustable, 840 mm - 860 mm (33.1 in - 33.9 in) 810 mm - 830 mm (31.9 in - 32.7 in) with low foam seat accessory 855 mm - 875 mm (33.7 in - 34.4 in) with mid/high foam seat accessory 870 mm - 890 mm (34.3 in - 35.0 in) with high foam seat accessory
Wheelbase
1,591 mm (62.6 in)
Rake
25.7°
Trail
120 mm (4.7 in)
Fuel tank capacity
22 l (5.8 US gal)
Number seats
2
Safety equipment
Riding Modes, Power Modes, Ducati Traction Control (DTC), Engine Brake Control (EBC), Bosch Cornering ABS, Ducati Brake Light (DBL), Ducati Cornering Light, Radar system, Ducati Vehicle Observer (DVO), Ducati Wheelie Control (DWC) DVO, Auto tyre calibration, Vehicle hold control
Standard equipment
Ducati Quick Shift (DQS) up/down 2.0, Type-approved Akrapovič muffler, Coming Home, TFT colour display, Hands-Free, Full LED headlight, Daytime Running Light (DRL), Self cancelling turn indicators, Full-map navigation system, 12V socket, USB port, Backlit handlebar switches, Adaptive Cruise Control, Ducati Electronic Suspension (DES) 2.0 con Öhlins Smart EC 2.0
Ready for
Additional LED lights, Tyre Pressure Monitoring System (TPMS), Hands-Free tank filler plug, Heated grips
Warranty
48 months, unlimited mileage
Valve clearance check
30,000 km (18,000 miles)
Standard
Euro 5+
Co emissions
170 g/km
Consumption
7.3 l/100km
