Type
Ducati V2 engine: 90° V2, 4 valves per cylinder, intake variable valves timing system, liquid cooled
Displacement
890 cc
Bore and stroke
96 x 61,5 mm
Compression Ratio
13.1:1
Power
85 kW (115,6 CV) @ 10750 rpm
Torque
92,1 Nm (9,4 kgm) @ 8250 rpm
Fuel injection
Electronic fuel injection system, Ø 52 mm throttle body with Ride-by-wire
Exhaust system
Stainless steel muffler, single catalytic converter and lambda probes
Gearbox
6 speed with Ducati Quick Shift (DQS) up/down 2.0
Primary drive
Straight cut gears; Ratio 1.84:1
Ratios
1=38/13, 2=35/17, 3=32/20, 4=29/22, 5=24/21, 6=26/25
Final drive
Chain; Front sprocket 15; Rear sprocket 40
Clutch
Hydraulically controlled slipper and self-servo wet multiplate clutch.
Frame
Monocoque Aluminium
Front suspension
Ø 45 mm fully adjustable mechanical fork, compression and rebound damping manual adjustment
Front wheel
Light alloy cast, 3" x 19"
Front tyre
Pirelli Scorpion Trail II 120/70 ZR 19
Real suspension
Fully adjustable monoshock, Remote spring preload adjustment, aluminium double-sided swingarm
Rear wheel
Light alloy cast, 4.5" x 17"
Rear tyre
Pirelli Scorpion Trail II 170/60 ZR 17
Wheel travel
170 mm / 170 mm (6.7 in / 6.7 in)
Front brake
2 x Ø 320 mm semi-floating discs, radially mounted Brembo monobloc 4-piston 2-pad calipers, radial master cylinder, Cornering ABS
Rear brake
Ø 265 mm disc, Brembo 2-piston floating caliper, Cornering ABS
Instrumentation
Digital unit with 5" TFT colour Display, 800 x 480 px Resolution
Wet weight
199 kg (no fuel)
Seat height
Adjustable, 830 mm - 850 mm (32.7 in - 33.5 in) 850 mm - 870 mm (33.5 in - 34.3 in) with high seat accessory 810 mm - 830 mm (31.9 in - 32.7 in) with low seat accessory
Wheelbase
1572,5 mm (61,9 in)
Rake
24,3°
Trail
105,5 mm (4,15 in)
Fuel tank capacity
19 l (5,02 US gal)
Number seats
2
Safety equipment
Riding Modes, Power Modes, Bosch Cornering ABS, Ducati Traction Control (DTC), Ducati Wheelie Control (DWC), Engine Brake Control (EBC), Ducati Brake Light (DBL) EVO
Standard equipment
Ducati Quick Shift (DQS) up/down 2.0, Full LED headlights with Daytime Running Light (DRL), Auto-off indicators, Coming Home, Cruise control, USB port
Ready for
Anti-Theft, Tyre Pressure Monitoring System (TPMS), Ducati Multimedia System (DMS), "Turn By Turn" navigator, Heated Grips, Lithium-ion battery, Front Fog Lights.
Warranty
48 months, unlimited mileage
Valve clearance check desmo
15,000 km (9,000 miles) / 24 months
Valve clearance check
30,000 km (18,000 miles)
Standard
Euro 5+
Co emissions
127 g/km
Consumption
5,5 l/100km
Notes
Bike specifications and equipment may vary from market to market. Please refer to your local dealer for further information
