Type
Desmosedici Stradale 90° V4, counter-rotating crankshaft, Desmodromic timing, 4 valves per cylinder, liquid-cooled
Displacement
1,103 cc
Bore and stroke
81 x 53.5 mm
Compression Ratio
14.0:1
Power
160.7 kW (218.5 hp) @ 13,500 rpm
Torque
122.1 Nm (12.45 kgm - 90.1 lb ft) @ 11,250 rpm
Fuel injection
Electronic fuel injection system. Twin injectors per cylinder. Full ride-by-wire elliptical throttle bodies. Variable length intake system
Exhaust system
4-2-1-2 system, with 2 catalytic converters and 6 lambda probes
Gearbox
6 speed with Ducati Quick Shift (DQS) up/down 2.0
Primary drive
Straight cut gears, Ratio 1.80:1
Ratios
1=36/15, 2=34/17, 3=33/19, 4=32/21, 5=30/22, 6=27/22
Final drive
Chain 520, Front sprocket 16, Rear sprocket 41
Clutch
Hydraulically controlled slipper dry clutch, Self bleeding master cylinder
Frame
Aluminium alloy "Front Frame" with optimised stiffnesses
Front suspension
Öhlins NPX 25/30 (SV) S-EC 3.0 pressurised 43 mm fully adjustable fork with TiN treatment. Electronic compression and rebound damping adjustment with Öhlins Smart EC 3.0 event-based mode
Front wheel
Forged aluminium alloy 3.50" x 17"
Front tyre
Pirelli Diablo Supercorsa SP-V4 120/70 ZR17
Real suspension
Fully adjustable Öhlins TTX36 (SV) S-EC 3.0 unit. Electronic compression and rebound damping adjustment with Öhlins Smart EC 3.0 event-based mode. Aluminium Hollow Symmetrical Swingarm
Rear wheel
Forged aluminium alloy 6.00" x 17"
Rear tyre
Pirelli Diablo Supercorsa SP-V4 200/60 ZR17
Wheel travel
125 mm (4.9 in) - 130 mm (5.1 in)
Front brake
2 x 330 mm semi-floating discs, radially mounted Brembo Monobloc Hypure® 4-piston calipers with Race eCBS. Self bleeding master cylinder.
Rear brake
245 mm disc, 2-piston caliper with Race eCBS
Instrumentation
Digital unit with 6,9" TFT display and Optical Bonding - 1,280 x 480 px resolution
Wet weight
185 kg (408 lb) (No Fuel)
Seat height
850 mm (33.5 in)
Wheelbase
1,485 mm (58.5 in)
Rake
24°
Trail
98 mm (3.86 in)
Fuel tank capacity
17 l - 4.49 gallon (US)
Number seats
Single seat
Safety equipment
Riding Modes, Power Modes, Race eCBS, Ducati Vehicle Observer (DVO), Ducati Traction Control (DTC) DVO, Ducati Wheelie Control (DWC) DVO, Ducati Slide Control (DSC), Engine Brake Control (EBC), Ducati Brake Light (DBL), Chain guard
Standard equipment
Ducati Power Launch (DPL) DVO, Ducati Quick Shift (DQS) up/down 2.0, Full LED headlights with Daytime Running Light (DRL), Ducati Electronic Suspension (DES) 3.0 with Öhlins Smart EC 3.0, Lithium-ion battery, Quick adjustment buttons, Pit Limiter, Auto-off indicators, Forged aluminium wheels, Akrapovič type-approved muffler with titanium alloy body and carbon fibre endcaps, Billet adjustable rider peg supports, Smoked racing windshield, Premium Alcantara seat, Billet brake and clutch levers, Billet upper triple clamp with laser-etched bike progressive number, Carbon fibre bodywork parts (full fairing, number plate holder, heel guards, front and rear mudguards, wings, pinion cover, swingarm guards, fuel tank covers, exhaust cover, chain cover, dashboard covers, rad-duct, tail covers, backrest, engine cylinder head cover), Dashboard key-on animation with bike progressive number, Ignition key with bike name and progressive number on aluminium plate
Provided equipment
Billet racing fuel tank cap*, Carbon fibre open clutch cover*, Carbon fibre ducts for brake cooling*, Transparent windshield, Billet aluminium handlebar balancing weights, Number plate support and rearview mirror removal kits*, Functional rider seat, Rear stand, Bike canvas, Authenticity certificate, Wooden shipping crate
Ready for
Ducati Data Logger (DDL), Anti-Theft, Cruise Control, Tyre Pressure Monitoring System (TPMS), USB port, Ducati Multimedia System (DMS), "Turn By Turn" navigator
Warranty
24 months unlimited mileage
Valve clearance check desmo
12,000 km (7,500 mi) / 12 months
Valve clearance check
24,000 km (15,000 mi)
Standard
Euro 5+
Co emissions
151 g/km
Consumption
6,5 l/100 km
Notes
*: Equipment not for road use Bike specifications and equipment may vary from market to market. Please refer to your local dealer for further information
